Screen and Display Protective Film

Manufacturing Specifications

Screen and Display Protective Film Manufacturing Specifications
Specification Available Options / Technical Parameters
Base Film Material Polyethylene (PE) / Polyethylene Terephthalate (PET)
Film Thickness PET: 30–80 μm; PE: 30–150 μm; customized according to display protection requirements
Adhesive Type Acrylic-based pressure-sensitive adhesive (PSA); customized adhesion formulations
Peel Adhesion PET: 0.3–8 N/25 mm; PE: 0.2–20 N/25 mm across the general product range
Low-Tack Film Options PET: 0.3–1 N/25 mm (SM-1003-1); PE: 0.2–0.8 N/25 mm (SM-1004-1); subject to display surface testing
Film Appearance Transparent / Clear; custom appearance options available
Functional Options Anti-static PET film available; other functional requirements subject to technical evaluation
Roll Dimensions Custom roll width, length and core size according to production equipment requirements
Converting Options Custom slitting, rolls, sheets and die-cut formats according to project requirements

Why Screen & Display Protection is Critical?

Why Screen & Display Protection is Critical
1. Prevent Surface Scratches And Abrasion

Protects screens and displays from physical damage caused by friction, tools, and daily handling.

2. Reduce Dust and Contamination

Minimizes dust, dirt, and particle adhesion, keeping surfaces clean throughout production and transport.

3. Protect Anti-Glare and Coating Layers

Safeguards delicate coatings such as anti-glare, anti-fingerprint, and optical layers from damage or degradation.

4. Maintain Clarity and Aesthetics

Preserves the original visual quality, ensuring high transparency and a flawless surface appearance.

5. Improve Handling Efficiency

Enhances grip and surface protection, reducing damage risks during manufacturing, assembly, and installation.

Solution for Different Screen and Display Types

Protective Film Solution for Smooth Screen and Display

Ultra-Smooth Surfaces

Common applications include smartphones and tablets, touchscreen panels, display monitors.

Protective Film Solution for Semi-Matte Screen and Display

Semi-Matte Surfaces

Common applications include laptop screens, office monitors and industrial HMI displays.

Protective Film Solution for Textured Screen and Display

Textured / Rough Surfaces

Common applications include industrial touch panels and outdoor displays.

Recommended Screen & Display Protective Solution

Screen & Display Protective Film Solution
Screen / Display Type Surface Characteristics Recommended Film Solution
LCD Panel Smooth, sensitive surface Low-adhesion transparent protective film
Touch Screen Delicate glass or coated panel Clean-removal film with stable low tack
Monitor / TV Display Large flat display area Transparent film with good surface coverage
Automotive Display Sensitive decorative screen Residue-free film with controlled adhesion
Plastic Display Window Scratch-sensitive plastic Low-tack protective film for plastic surfaces
Industrial Control Panel Frequent handling during assembly Durable film with balanced adhesion

Industries We Serve

Protective Film for Consumer Electronics

Consumer Electronics

Applied to smartphone screens, tablets, laptops, display panels, and wearable screens.

Protective Film for Automotive Electronics

Automotive Electronics

Used on infotainment displays, instrument clusters, navigation screens, and touch panels.

Protective Film for Home Appliances

Home Appliances

Applied to display or control panels of appliances like ovens, refrigerators, and washing machines.

Custom Monitor Screen Protective Film for Computer Labs

Custom Monitor Screen Protective Film for Computer Labs
Project Detail Specification / Requirement
Application Computer lab monitors
Monitor Model Dell U2722DT
Film Material Transparent PET
Key Requirements Screen protection, high clarity, no privacy filtering
Customization Screen dimensions, adhesion strength, film thickness

Get in Touch with Us

    FAQs

    Common materials include PE, PET, acrylic PSA, and other customized polymer films.

    We offer PET films from 30–80 μm and PE films from 30–150 μm, with customized thickness options available.

    Yes, we customize adhesive formulations to match different display surfaces, ensuring stable adhesion, clean removal, and minimal residue.

    Yes, we provide precision slitting with customized roll widths and lengths to meet specific display manufacturing and assembly requirements.

    Yes, we offer anti-static PET protective film options to reduce static buildup during display manufacturing, handling, and assembly.

    Yes, our low-adhesion films can protect AG and AF coatings, subject to surface compatibility and clean-removal testing.

    Please provide display surface type, film material, thickness, adhesion requirements, roll dimensions, order quantity, and any special performance requirements.
